GREASE HIGH PRESSURE HOSE REELS
Product Details:
- Function Hand Tools
- Features Durable
- Surface Finish Smooth
- Tool Type hose reels
- Material Carbon Steel
- Click to View more
X
GREASE HIGH PRESSURE HOSE REELS Product Specifications
- hose reels
- Carbon Steel
- Hand Tools
- Smooth
- Durable
Product Description
Metal Hose Reels
- Strong & sturdy hose reels with an all metal construction with a ribbed steel disk that prevents bending & flexing.
- Rolled edges for added strength & stability Compact design allows these to be used in confined spaces with ease
- Cassetted Spring Design: Drive springs are manufactured from highest quality spring steel that ensures long life. Precise manufacturing guarantees a superior quality edge. Fully enclosed cassette design makes the spring resistant to corrosion caused by water & dirt, guaranteeing longer life & trouble free operation. Further thisdesign makes it easy & safe for maintenance
- Ratchet: Heavy duty dual ratchet reduces stress on spring providing smooth & balanced operation during hose extension & retraction.
- Dual ratchet teeth can lock hose in multiple usable positions
- Multiple Position Guide Arm: Guide arms can be adjusted at 45° intervals that provides versatile floor, wall or truck mounting with a convenient mounting angle for hose to be released at optimum position
- Reels are available with two options of guide arms: Dual guide arm option for medium & high pressure applications involving grease & oils. Dual guide arm design is structurally reinforced strengthened with metal ribs that prevent flexing and bending due to hose pull. Single guide arm option for low pressure applications involving air and water
- Adjustable roller guide arm with nylon guide rollers reduces drag & wear Inlet swivel reduces torque load on power spring for smoother hose movement & durability 1/4" (6.35 mm) thick steel base with easy mounting eyelet hole
- All components are powder coated after cleaning, degreasing & phosphating ensuring a long lasting, durable & attractive finish.
- Hose reels come with an option of I0m (32.8') & 15m (49.2') hose
- Hose Reel accessories for floormounting & angular mounting on walls are also available
SPARE PARTS & KITS
| CAT NR. | DESCRIPTION | BOX QTY. |
| KIT/CSPR-HR-OL | Coil Spring Repair Kit | 1 |
| KIT/SFT/HR | Shaft Repair Kit | 1 |
ORDERING INFORMATION
| Cat | Max Pressure | Inlet/ Outlet | Hose ID | Hose OD | Hose Length | Box Qty. | ||
| Inch | Inch | mm | Inch | mm | m | |||
| GREASE - HIGH PRESSURE HOSE REELS | ||||||||
| HR/GR/10M/1-4/B | 5,000 PSI | 1/4 | 1/4 | 6.35 | 5/8 | 15.9 | 10 | 1 |
| HR/GR/15M/1-4/B | 5,000 PSI | 1/4 | 1/4 | 6.35 | 5/8 | 15.9 | 15 | 1 |
| HR/GR/10M/3-8/B | 4,000 PSI | 3/8 | 3/8 | 9.5 | 3/4 | 19 | 10 | 1 |
| HR/GR/15M/3-8/B | 4,000 PSI | 3/8 | 3/8 | 9.5 | 3/4 | 19 | 15 | 1 |
