Mechanical Heavy Duty Oil Control Gun

Get a Price/Quote

Product Details:

Surface Finish Smooth
Features Durable
Function Hand Tools
Tool Type oil control rings
Material Carbon Steel
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Mechanical Heavy Duty Oil Control Gun Product Specifications

Tool Type oil control rings
Surface Finish Smooth
Features Durable
Material Carbon Steel
Function Hand Tools

Product Description

Mechanical Heavy Duty Oil Control Gun

Heavy duty industrial oil control gun with robust aluminium construction & a rubberised shroud for protecting the meter
Oval gear mechanism for optimum accuracy
Latching handle with built-in trigger lock for continuous dispensing
Gun has 2 outlet positions: in-line & 90
Built in swivel at inlet
Supplied complete with steel extension with automatic non-drip nozzle
RECOMMENDED USE Engine Oils, Diesel, ATF, Antifreeze, Antiboil & other Petroleum Based Media Upto SAE 140

SPECIFICATIONS

Flow Rate	1 to 30 LPM
Accuracy	1%
Repeatability	0.20%
Max. Working Pressure	1,500 PSI (70 BAR)
Working Temperature Range	0C to 50C
Max. Resettable Batch Totalizer	999.9 litres
Max. Non Resettable Batch Totalizer	9,99,999 litres
Least Count /Resolution	0.10 litres
Inlet Threaded	1/2" BSPT (F)
Water Resistance	IP55

FLOW RATE: 1-30 LPM
PRESSURE: UPTO 1,500 PSI (100 BAR)
TEMPERATURE: 0C TO 50C

ORDERING INFORMATION

CAT NR.	BOX QTY.
HG40R/B	1
