Torque Multipliers
Product Details:
- Features Durable
- Function Hand Tools
- Surface Finish Smooth
- Tool Type torque multipliers
- Material Carbon Steel
- Click to View more
X
Torque Multipliers Product Specifications
- Hand Tools
- Durable
- torque multipliers
- Smooth
- Carbon Steel
Product Description
Torque Multipliers
- Heavy duty torque multiplier provides mechanical advantage in applying high torque to tighten nuts & bolts
- Particularly used for high torque application
- Chrome Vanadium construction with Chrome Molybdenum square drive & Chrome Molybdenum reaction bar
- Planetary gear train mechanism multiplies the input torque as per the multiplication factor to deliver the output torque
- Torque multiplicative factor reduces operator effort by upto 75%
- Replaces the use of long levers, which can be potentially dangerous
- Includes breakaway adaptor to prevent damage to the multiplier in case excess torque is applied
- Comes complete with straight reaction bar, breakaway adaptor & hex key in a blow moulded case
Specification
| Description | 1:6.5 TORQUE MULTIPLIER 1500 Nm (1100 ft-lb) | 1:3.3 TORQUE MULTIPLIER 2500 Nm (1840 ft-lb) |
| Max. Torque | 1500 (1100 ft-lb) | 2500 (1840 ft-lb) |
| Torque ratio | 1 : 6.5 | 1 : 3.3 |
| Gear ratio | 1:9 | 1:4 |
| Max. Input torque | 231 Nm (170 ft-lb) | 758 Nm (560 ft-lb) |
| Max. Output torque | 1500 Nm (1100 ft-lb) | 2500 Nm (1840 ft-lb) |
| Input drive | 1/2" | 3/4" |
| Output drive | 3/4" | 1" |
| Accuracy | ± 10% | ± 10% |
ORDERING INFORMATION
| CAT NR. | MAX. TORQUE | BOX QTY. | |
| (NM) | (FT-LB) | ||
| TQM/1-2/3-4/15 | 1500 | 1100 | 1 |
| TQM/3-4/0-1/25 | 2500 | 1840 | 1 |
