3-8 inch Ratchet Wrench Standard
Product Details:
- Function Hand Tools
- Surface Finish Smooth
- Features Durable
- Tool Type ratchet wrenches
- Material Carbon Steel
- Click to View more
X
3-8 inch Ratchet Wrench Standard Product Specifications
- Durable
- ratchet wrenches
- Hand Tools
- Carbon Steel
- Smooth
Product Description
The 3-8 inch Ratchet Wrench Standard allows you to work on multiple fastener types. They are constructed of high grade material and are heat treated for strength & durability. They can be used for professional grade garage works. Apart from this they are known for their superior grip and durability.
- Robust & durable aluminium housing
- Heat treated ratchet head design provides longer life
- Chrome Molybdenum anvil guarantees high performance in the toughest applications
- Optimized gear ratio and air flow for reliable performance
- Easy to use forward/reverse control
- Throttle lever design for easy speed control
- Compact and light weight, ideal for use in confined work spaces
- Excellent for body shop repair jobs and light duty work under the dashboard
| MAX TORQUE* | Free Speed | Net Weight | AVG. AIR CONSUMPTION |
| 68 Nm (50 ft-lb) | 150 RPM | 1.17 KG (2.58 LB) | 6 CFM (170 LPM) |
SPARE PARTS & KITS
| Cat NR. | Description | Box Qty. |
| BBR-1/RTW/1-2/3-8/STD | Ball Bearing (Rear End) | 1 |
| BLD/RTW/1-2/3-8/STD | Rotor Blade | 1 |
| BBR-2/RTW/1-2/3-8/STD | Ball Bearing(Front End) | 1 |
| WSR-1/RTW/1-2/3-8/STD | Washer | 1 |
| IGEAR/RTW/1-2/3-8/STD | Internal Gear | 1 |
| GEAR/RTW/1-2/3-8/STD | Gear | 1 |
| PIN-1/RTW/1-2/3-8/STD | Pin | 1 |
| PCAGE/RTW/1-2/3-8/STD | Planet Cage | 1 |
| RBR/RTW/1-2/3-8/STD | Roller Bearing | 1 |
| CRSFT/RTW/1-2/3-8/STD | Crank Shaft | 1 |
| BDRV/RTW/1-2/3-8/STD | Bushing Drive | 1 |
| YOKE/RTW/1-2/3-8/STD | Yoke | 1 |
| WSR-2/RTW/1-2/3-8/STD | Washer | 1 |
| PIN-2/RTW/1-2/3-8/STD | Pin | 1 |
| RAVL/RTW/3-8/STD | 3/8" Ratchet Anvil | 1 |
| SB/RTW/3-8/STD | Steel Ball | 1 |
| SPR-1/RTW/1-2/3-8/STD | Spring | 1 |
| SB/RTW/1-2/3-8/STD | Steel Ball | 1 |
| PAWL/RTW/1-2/3-8/STD | Pawl | 1 |
| WSR/RTW/3-8/STD | Washer | 1 |
| SPR-2/RTW/1-2/3-8/STD | Spring | 1 |
| LOCPIN/RTW/1-2/3-8/STD | Lock Pin | 1 |
ORDERING INFORMATION
| CAT NR. | Free Speed | Max. Torque | AIR INLET SIZE | AIR HOSE I.D. | AVG. AIR CONSUMPTION | Overall Length | Net weight | Box Qty. | ||||
| (RPM) | (FT-LB) | (NM) | (INCH) | (INCH) | (CFM) | (LPM) | (INCH) | (MM) | (KG) | (LB) | ||
| RTW/3-8/STD | 150 | 50 | 68 | 1/4 | 3/8 | 6 | 170 | 10.5 | 267 | 1.17 | 2.58 | 1 |
