Mini Bowser Diesel Refilling System

Get a Price/Quote

Product Details:

Features Durable
Function Hand Tools
Surface Finish Smooth
Tool Type fuel handling systems
Material Carbon Steel
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Mini Bowser Diesel Refilling System Product Specifications

Surface Finish Smooth
Material Carbon Steel
Tool Type fuel handling systems
Features Durable
Function Hand Tools

Product Description

Mini Bowser Diesel Refilling System

A compact & convenient system designed for all stationary diesel refilling applications
Extremely versatile, the bowser can be installed directly on a wall, on an existing structure with screws or directly on a tank
The dispensing system is equipped with a continuous usage self- priming diesel pump, high precision mechanical meter, nozzle & hose: encased in sturdy,weather-proof metal housing. This casing has an in-built nozzle holder, nozzle hangar & a lever ON/OFF switch

Continuous Duty Electric Fuel Pump Self priming, vane pump with an integral bypass valve is equipped with a self ventilated, 1/2 HP motor with thermal overload protection. This makes it suitable for continuous usage

Mechanical Diesel Meter Nutating disc mechanical meter with litre display, flow rate of 20-120 LPM & pressure rating 145 PSI

Fuel Control Nozzle Automatic Dual mode nozzle - Manual & Automatic. Sensor in the discharge spout outlet automatically shuts off
supply when fuel level in the tank reaches the discharge spout. The nozzle is equipped with a swivel at the inlet for convenience in usage

Fuel Hose 3.6m (10.5') x 1" (ID) long antistatic fuel hose

Nozzle Holder In-built into the metal casing for keeping hose safe when not in use

Hose Hangar For safe storage of nozzle

FLOW RATE: UPTO 44 LPM

METER ACCURACY : 1%

SPECIFICATIONS

System / Bowser Description	220V AC
Inlet / Outlet	1" BSP (F)
Pump Motor	1/2 HP 220V AC, 50 Hz
Pump Rpm	2700
Duty Cycle	Continuous Duty
Power Cable Length	2m
Meter Accuracy	1%
Meter Least Count	0.10 litres
Max. Resettable Batch Total	999.9 litres
Max. Non Resettable Totalizer	999999 Litres
Hose Length	3.6m 1" ID

ORDERING INFORMATION

CAT NR.

DESCRIPTION

INLET / OUTLET

BOX QTY.

CBN/220EU/L/A

1/2 HP 220V AC,

50/60 Hz. power cord

1" BSP
